The Konus Flame 0.6×2.4 thermal monocular delivers advanced imaging in a compact, lightweight package, ideal for night and day observations in outdoor, airsoft, surveillance, and research scenarios. Featuring a high-sensitivity 160×120-pixel sensor and a 6.2 mm lens, it rapidly converts heat signatures into clear images on a 0.2″ LCOS display (720×540 resolution), enabling detection and identification at varied distances.

Vanadium Oxide uncooled thermal sensor, 160×120 pixels, NETD <35 mK (@25 °C), 8–14 µm spectral band; ensures high thermal sensitivity and detail in challenging conditions.

Digital zoom 0.6×–2.4×, suitable for close to mid-range observation; approximately 14.7°×18.7° field of view provides broad monitoring area.

0.2″ LCOS display at 720×540 resolution with Flat Field Correction (auto, manual, external) for uniform images, artifact reduction, and enhanced contrast.

Four selectable palettes (Black Hot, White Hot, Red Hot, Fusion) to tailor visual output to environment and lighting conditions.

Hot Track feature (“find the hottest spot”) to quickly highlight the highest temperature point in view.

Photo and video recording to internal 8 GB memory, with live streaming or transfer via built-in Wi-Fi hotspot: ideal for documentation and post-analysis.

Built-in rechargeable 18650 battery: up to 10 hours continuous use with Wi-Fi off, around 7.5 hours with hotspot active, battery status display included.

Rugged, waterproof IP67-rated housing: withstands temporary immersion and harsh weather; about 158 mm length and 250 g weight, easy to carry.

USB Type-C interface for charging and data transfer; operates in wide temperature range (-20 °C to +55 °C).

Tripod mountable for stable high-zoom observations or extended sessions.

Ergonomic design for handheld use or fixed mounting.

User experience
With the Konus Flame 0.6×2.4, users enjoy detailed thermal imagery even in complete darkness, quickly adjusting zoom as needed. Multiple palettes and Hot Track speed up detection of warm targets, while integrated recording and Wi-Fi allow immediate saving and sharing of footage. Long battery life and durable build suit extended field use, and tripod compatibility ensures steadiness for prolonged observations.

Warnings and usage information (compliant with Italian GPSR regulations)

Keep out of reach of children: device contains small parts (lens caps, screws) that pose ingestion or choking hazards if mishandled.

Never look directly at bright light sources (sun, headlights) through the optics or display: severe eye injury risk.

Store and use in dry conditions, away from heat and excessive humidity, to preserve seals, optics, and electronics.

Before any maintenance or handling, power off the device and remove any external power; always follow safety procedures.

Clean external optics with microfiber or lens-specific cloths; avoid harsh solvents that may damage multi-coated lenses.

Do not disassemble the unit: opening the housing voids seals, misaligns internals, and compromises waterproofing and calibration.

Tampering or modifying any structural, optical, or electronic component is forbidden: unauthorized changes can impair safety, reliability, and longevity, causing sudden failures.

When mounting on a tripod, ensure proper attachment and overall stability: abrupt movements or vibrations can damage the device.

Perform power-on and function checks in a safe, controlled environment (e.g., low-light area), verifying IR illumination, zoom, palettes, and recording before critical use.

Recharge battery only with appropriate chargers; replace with manufacturer-approved cells to prevent malfunctions or damage.

Use protective case when not in use and handle gently to avoid severe impacts; after any significant drop, inspect optics and housing before reuse.

Any advanced maintenance (internal repairs, calibrations) should be carried out by qualified technicians or authorized service centers to preserve factory specifications.

Avoid use beyond manufacturer specifications (e.g., prolonged immersion beyond IP67 rating or exposure to extreme temperatures outside the range).

Improper use or unauthorized modifications may void warranty or cause irreparable damage.
