Thermal systems Konus Flame 0.6X-2.4X 7953

Thermal systems Konus Flame 0.6X-2.4X 7953


While being very compact and competitively priced, our #7953 model is among the most versatile on the market.
It allows you to choose from 4 different palettes, has a photo/video recording function and is also capable of transferring thermal images via wi-fi, so you can view them live on your mobile phone if you wish.

1 IN STOCK
  • Pay in 3 interest-free instalments
    Pay in 3 interest-free instalments
  • Shipments orders in 24h with express curier (see conditions of sale)
    Shipments orders in 24h with express curier (see conditions of sale)
  • Guaranteed return (see conditions of sale)
    Guaranteed return (see conditions of sale)
  • Availability of warehouse updated in real time
    Availability of warehouse updated in real time
  • Secure payments
    Secure payments
€499.00
€599.00
Save €100.00
Tax included
This is the lowest price within 30 days before promotion
€599.00 in the last 30 days
Delivery in 3/5 days with conditions
qty
Available

While being very compact and competitively priced, our #7953 model is among the most versatile on the market.
It allows you to choose from 4 different palettes, has a photo/video recording function and is also capable of transferring thermal images via wi-fi, so you can view them live on your mobile phone if you wish.
In addition, having a 0.6x-2.4x zoom system and a larger display with an improved field of view, it significantly outperforms the competition optically as well.

• MONOCULAR THERMAL VIEWER
• MAXIMUM RESOLUTION 160X120 PIXELS WITH HIGH SENSITIVITY SENSOR
• BUILT-IN RECHARGEABLE LITHIUM BATTERY
• HOT SPOT FOR WIFI CONNECTION
• ZOOM MAGNIFICATION FROM 0.6X TO 2.4X
• 8GB BUILT-IN MEMORY CARD
• WATERPROOF
• ALLOWS TO TAKE PHOTOS AND RECORD VIDEOS

SEEING DISTANCE (1.4X4M VEHICLE): 559M
SIGHTING DISTANCE (HUMAN 1.8X0.5M): 200M
RECOGNITION DISTANCE (1.4X4M VEHICLE): 140M
RECOGNITION DISTANCE (HUMAN BEING 1.8X0.5M): 46M
IDENTIFICATION DISTANCE (1.4X4M VEHICLE): 70.M
IDENTIFICATION DISTANCE (HUMAN 1.8X0.5M): 23M
WEIGHT: 250G
LENGTH: 158.3MM

THERMAL MODULE:
IMAGE SENSOR: vanadium oxide uncooled Focal Plane arrays
MAXIMUM RESOLUTION: 160×120
PIXEL INTERVAL: 17μm
RESPONSE WAVEBAND: 8 μm to 14 μm
NETD: less than 35mk (@25°c), F#=1.0
LENS (FOCAL LENGTH): 6.2mm
FIELD OF VIEW: 14.7°x18.7° (Hxv)
DIGITAL ZOOM: 0.6x to 2.4x
APERTURE: F1,1
MAGNIFICATION: 0.6 to 2.4

PICTURE DISPLAY
MONITOR: 0.2 inch, lcos, 720×540
FFC (FLAT FIELD CORRECTION): auto, manual, external correction
PALETTES: Warm Black, Warm White, Warm Red, Fusion
PICTURE FREQUENCY: 50Hz

ADDITIONAL FUNCTIONS:
FIND THE WARMEST SPOT: YES
WI-FI HOT SPOT: YES
STAND-BY MODE: YES

SYSTEM:
STORAGE: Built-in 8GB memory module
VIDEO RECORDING: YES
TAKE IMAGES: YES
POWER SOURCE:
BATTERY TYPE: Built-in 18650 lithium battery
BATTERY LIFETIME: 10 continuous hours with CVBS and WI-FI hot spot off (@25°c)
7.5 continuous hours with CVBS and Wi-Fi hot spot on (@25°c)
DISPLAY OF THE STATUS OF THE BATTERY: YES
GENERAL:
POWER SUPPLY: 5vdc/2a, 1.5W,type-c Interface
WORKING TEMPERATURE: from -20°c to 55°c
LEVEL OF PROTECTION: IP-67 waterproof, submersible
DIMENSIONS: 158.3mmx61mmx57mm
WEIGHT: 250GR.

KONUS
6236

Data sheet

Color
Green
Model
KONUS Flame
Tipo
Cannocchiale
Ingrandimento massimo
2,4x
Caratteristiche
Impermeabile
Peso
250 g
Rivestimento obiettivo
Interamente rivestito
Diametro lente obiettivo
Fino a 20 mm
Applicazione
Birdwatching
Dimensioni
Compatto
Larghezza
57 mm
Lunghezza
158 mm
